SmartConnect Touchscreen 1 Loop Addressable Fire Alarm Panel

The SmartConnect is a fully featured single loop addressable fire alarm panel with a user friendly 4.3 inch touch screen display and remote monitoring via a desktop PC or smartphone via the cloud.

The panel is housed in an attractive, modern designed, flame retardent ABS enclosure, utilising a switch mode power supply and has a fully removable front cover which improves ease of access for cable installations. Up to 16 panels can be networked (peer to peer) with no additional network cards.

• 4.3 inch colour touch screen display
• Remote monitoring via a desktop PC or smartphone via the cloud
• Easy to use configuration software
• Full cause & effect programming via front panel or PC
• 250 Zeta MKII protocol devices per loop
• 250 available zones, 16 with LED indication
• Built-in TCP-IP output
• Up to 8 password protected users
• Meets all requirements of latest EN54 parts 2 & 4
• Extensive Day/Night mode programming
• Built-in network facility
• 2 programmable local inputs
• 2 sounder circuits
• Fire & fault relays

• Mains Voltage : 230V AC +10% / -15% @ 50/60 Hz
• System Voltage : 24V DC (Nominal)
• Loop Current : 500mA
• Sounder Alarm Output : 2 x 200mA @ 24V DC
• Fault Relay : 1 x Volt Free Relay, SELV @ 1A Max
• Fault Relay : 1 x Volt Free Relay, SELV @ 1A Max
• Loop Capacity : 250 MKII devices
• Charger Voltage : 27.6V
• Battery Cut Off : Battery voltage less than 20V
• Battery Internal : Resistance limit 2.0 ohm
• Enclosure Size : 370 x 311 x 113 (mm)
• Weight : 3.5Kg
• Maximum Battery Space : 2 x 7.0 Ah, 12 Vdc sealed lead acid
• IP Rating : IP30
